Heavy head
PTS-3082
Features
304/316L stainless steel material;
Surface spray treatment, anti-aging, anti-corrosion, waterproof, acid rain;
Protection level IP67.
Parameters
Horizontal rotation range |
0 ° ~ 355 ° / 0 to 360 |
Vertical rotation range |
35 ° to 45 ° ~ + |
Horizontal rotation speed |
13°/S |
Vertical rotation velocity |
1.8 ° / S |
Communication mode |
RS485 bus (customized remote control) |
Communication protocol |
Pelco-D/Pelco-P |
Angle setting query |
Support Angle setting and query |
Baud rate |
1200bps/2400bps/4800bps/9600bps |
Transmission mode |
Worm gear drive |
Two line sweep |
One route, two points can be set |
Two point line sweep speed |
The value ranges from 6.5 to 13°/S |
Number of preset bits |
The value ranges from 1 to 128 |
Address code |
The value ranges from 0 to 64 |
Ambient temperature |
- 30 ℃ ~ + 60 ℃ |
Ambient humidity |
≤95% No condensation |
Maximum load |
20Kg |
Class of protection |
IP67 |
Driving power supply |
AC24V/2A 50/60Hz |
Overall dimension |
207*170*332mm |
weight |
15.2 Kg |
Outline Dimensional Drawing
